Name: VE-B15 Biological Trinocular Microscope w/ Plan-Achromatic Optics and Infinity Correction
SKU: 665782

VE-B15 Biological Trinocular Microscope w/ Plan-Achromatic Optics and Infinity Correction

$ 27.45

$ 0.00

Save: $

Unavailable

Please select combo product attributes

The combo subtotal is $,SAVE$

The VE-B15 is a trinocular microscope, ideal for research, higher education and routine work in clinical laboratories. Its plan achromatic objectives with infinite correction offer improvement of optical aberrations for the observation of higher quality images. It has objectives that provide a wide field of observation and its Kohler LED lighting makes it a very complete and versatile device.

It is adaptable to the needs of the user, its third eyepiece allows the integration of digital devices for data storage and it is also compatible with the optional configuration for the polarization set.

Especifications

Eyepieces	WF 10X/22 mm.
Nosepieces	Quadruple
Objectives	4X, 10X, 40X, 100X (S) (oil)
Optical System	Infinity-Corrected Plan Achromatic.
Stage	Double layer with coaxial movement X-Y 150 x 132 mm / 5.9” x 5.1”.
Condenser	Abbe, N.A. 1.25 with elevator
Diaphragm	Iris type
Focus	Coarse and fine anti-slip control knob
Ilumination	Kohler LED
Dimensions	180 x 410 x 285 mm / 7” x 16.1” x 11.2”.
Power supply	Three 1.2V AA rechargeable batteries (included). 110/240, 50/60 Hz AC Adapter.
Main Features	Diopter adjustment in an eyepiece. Siedentopf type Trinocular Head. Head inclined at 30 ° and rotatable 360° Interpupillary distance of 48 ~ 75 mm. Phototube with 23 mm diameter, compatible with VELAB MC, LX series cameras and VE-SCOPEPAD tablet. Stable, robust, reinforced and easy to transport. Lighting with intensity adjustment and field diaphragm in lamp for Kohler illumination. Stage with vernier, millimeter scale, caliper and stop with height adjustment. Objectives with colored rings.
Applications	Education: Upper grade levels Research Clinical
Accessories Included	Power cord Dust cover Immersion Oil Color filters green, yellow and blue
Warranty	10 years
